Buildings destruction for RTS games

Hello dear readers!

I've been working on my RTS game for about 3 years, using my personal game engine, and one of the things I'm really happy with is the way buildings are demolished, have a look -

We are a very small team, so I had some important conditions for destruction system

• It need to be easy to set up, because we don't have time and resources to i.e. decompose meshes and then animate them
• It need to be reliable because I can't be coming back to it once it's done
• It need to look cool and make my game stand out among dozens of other RTS games

Those points are especially important because we expect the community to make mods for our game, and our destruction solution should work out of the box for them.

So here's how it's done in The Scouring.

Part 1. Setup

All the artist need to do is attach mesh blobs to parts of the building that he wants to come off, like this -

We use about 100-150 blobs for buildings, and it takes just a couple of hours to set them up.

And that's it.

Part 2. Mesh Processing

Most destruction systems use geometric intersections (boolean operations) to break mesh into pieces. However, it is a very slow and complex process that generally requires the mesh to be constructed in a specific, “correct” way.

Instead we use alpha-clipping to break the mesh into pieces.

2.1. So the first thing is to generate blob intersections against the original mesh.

These are our chunks that will break off the building.

We also generate the “backsides” of each hole.

This might be the trickiest part of the whole thing, but I would not like to go into details of it as it is very technical. Get in touch with me if you need more details.

2.2. Next, generate a texture atlas for our building

There are publicly available libraries that can do that, I used https://github.com/jpcy/xatlas.

For an RTS camera and a building like that, 512x512 atlas has enough accuracy.

2.3. Iterate every pixel in the atlas, and mark it with chunk id when the corresponding 3d position on the building surface is within one of the “blobs”

This is the most time-consuming process (relatively speaking, the whole process described in this paper takes 0.25 ms on my 10 years old PC).

The most important thing to speed things up is to assume all blobs to be “convex” (and there is no reason not to do so).

Checking if a given point is inside a 3d convex hull is trivial. And there is a public library that generates convex hulls - https://github.com/akuukka/quickhull

Part 3. Runtime

So when a unit hits a building, we detect the chunk that is closest to the hit position, and mark it as active. Each building has a texture buffer with the size of “n chunks”, storing a boolean for each chunk, whether it is active or not.

In pixel shader, we read the texture atlas storing chunks id’s, and do a clip if this chunk is active.

We also need to show the “backside” of a clipped hole. We render the “backsides” mesh, with the inverted logic of the check mentioned above (if a chunk is active - DON’T clip the backside).

And of course the chunk itself. If the building is visible, we spawn a physical body for it. If not, we simply activate it in its resting position (next to the building).

We only use 3 calls to draw the whole thing:

1. Building itself
2. Backsides
3. Chunks. We put all of the chunks geometry into a single geometry buffer, and use the same texture buffer in pixel shader to clip-out inactive chunks.

When the building is being repaired, instead of activating the chunks, we deactivate them.

Last (but not least) a few notes about additional effects.

We separate the building into “burnable” and “static” parts. The “burnable” part slides down when the building is destroyed, and has some fancy shader effects applied to. The “static” parts simply dissolves (using a screen-space per-pixel technique)

Thank you for reading!

If you have any questions, please fire at [email protected]!

And please check out our game on Steam!

https://store.steampowered.com/app/3338950/The_Scouring/
